3PE Coating Elbow

Elbow size: 1/2'' to 180''

Elbow radius: 1D,1.5D

Elbow Degree: 30,45,60,90,180.

Elbow Thickness: SCH10 to SCH XXS

Related Standard&Specification: API, EN, ASTM, DIN, BS, JIS, GB

Related Grade: A234,A182,A105,A350,A403,A420,A860,A694,A815,AWWA C208

Available Approved Marine: ABS/BV/LR/DNV/GL/KR,EN10204 3.2MTC

Special Service: Sweet Service, Sour Service, Anti-H2S, NACE MR0175/ISO15156

Produce Process: Hot Forming,Welded by Plate,Cold Forming,Forging by bar

3PE pipe coated with Epoxy inside, adhesive layer middle, and outside with polyethylene layer.

3PE can strengthen the pipeline’s mechanical properties, high electrical resistance, waterproof, wearable, anti-aging.It could protect pipe from the heat loss which only account for 1/4 of pipe.

3PE anti-corrosion pipe three-tier structure:
the first layer of epoxy powder (FBE> 100um), the second adhesive (AD) 170-250um, the third layer of polyethylene (PE) 2.5-3.7mm.
Three of the integration, and steel pipe with a good solid coating. Diameter of Φ159-Φ1220.

3PE coating pipe integrated with the advantages of FBE and the PE. Which is geting more and more widely used in buried pipeline’s transporting of water, gas and oil.
